Insulated XPS Composite Panel 2800x1200x30mm
Part number ATP-ACC-14 · XPS Insulated Panels
Price on application: request a quote · Enquiry
High-performance thermal insulation sandwich panel manufactured with high-density extruded polystyrene (XPS) closed-cell foam core laminated between smooth food-grade FRP gelcoat skins. Delivers outstanding thermal insulation (low thermal conductivity) and zero moisture absorption for temperature-controlled transport.
Fits: Suits refrigerated van bodies, chiller boxes, and temperature-controlled food transport
Specifications
| Dimensions | 2800 x 1200 x 30mm (3.36 m²) |
|---|---|
| Surface Area | 3.36 m² |
| Product Parameter | Dimensions: 2800 x 1200 x 30mm | Area: 3.36m² | Core: High-Density Extruded Polystyrene (XPS 38-42 kg/m³) | Facings: 1.5mm Food-Safe Gloss White FRP | Thermal Conductivity: λ ≤ 0.028 W/m·K |
| Technical Specification | Closed-cell thermal sandwich panel for refrigerated truck bodies, chiller vans, and temperature-sensitive pharmaceutical haulage. |
| Certification | AS/NZS ISO 9001 Approved; HACCP Food Safety Compatible; AS 4256.3 Standards Compliant |
| Australian Standard | AS/NZS ISO 9001 Approved; HACCP Food Safety Compatible; AS 4256.3 Standards Compliant |
