F-Track Spring-Loaded End Fitting with 50mm Webbing Strap
Part number ATP-TP-16 · Cargo Control
$25.00 AUD · In stock VIC
Heavy-duty steel end fitting engineered specifically for standard F-series vertical and horizontal logistics track. Features a spring-loaded plunger locking pin for positive, rattle-free engagement and is factory assembled with a high-tenacity 50mm polyester webbing strap loop for connecting ratchet buckles, tie-down hooks, or cargo nets.
Fits: Suits curtains and straps
Specifications
| Use | Curtains |
|---|---|
| Type | End fitting |
| Australian Standard | AS/NZS ISO 9001 Commercial Transport Standard Approved |
| Certification | AS/NZS ISO 9001 Approved Commercial Transport Standard; AS/NZS 4380 Compliance |
| Track System | Standard F-Track (Series F logistics track slots) |
| Pin Diameter | 19mm (3/4") Spring-Loaded Plunger Pin |
| Strap Width | 50mm (2") High-Tenacity Polyester Webbing |
| Material | Forged & Stamped Steel with Yellow/Clear Zinc Chromate Plating |
| Breaking Strength | 1,800 kg (4,000 lbs) |
| Working Load Limit | 600 kg (1,320 lbs) WLL |
| Dimensions | L140mm x W50mm x D25mm |
