Hydraulic Power Unit 12V 2.2kW c/w Accessories
Part number ATP-TL-06 · Power Units
Price on application: request a quote · Enquiry
The Aurex PowerPack 12V-Pro is an electro-hydraulic power unit engineered as a drop-in replacement or retrofit power system for commercial cantilever tail lifts, tippers, and vehicle loading hoists. Powered by a heavy-duty 12V DC 2.2 kW starter-grade electric motor coupled to a high-pressure precision gear pump, it delivers 5.8 L/min nominal oil flow at pressures up to 21 MPa (210 bar). Features an 8-litre steel oil reservoir, integrated 12V cartridge lowering solenoid valve with emergency manual lowering bypass, heavy-duty 150A starter solenoid, pre-wired IP65 control harness, and multi-hole mounting subframe.
Fits: Suits tail lift systems
Specifications
| Product Type | Universal Electro-Hydraulic Power Unit Assembly |
|---|---|
| Motor Voltage | 12V DC |
| Motor Output Power | 2.2 kW high-torque starter-grade motor |
| Pump Type | High-pressure precision gear pump (2.1 cc/rev, nominal delivery 5.8 L/min) |
| Maximum Working Pressure | 21 MPa (210 bar) with user-adjustable internal relief valve |
| Reservoir Capacity | 8.0 Litre heavy-gauge powder-coated steel tank with breather cap and sight level |
| Directional & Lowering Valving | 12V DC cartridge lowering solenoid valve with emergency manual override screw |
| Electrical Switching | Heavy-duty 150A starter solenoid relay with weather-sealed boots |
| Harness & Control Loom | Pre-wired IP65 wiring harness with terminal connectors and fuse protection |
| Mounting Subframe | Universal slotted steel bracket for horizontal or vertical chassis mounting |
| Hydraulic Ports | Standard G3/8" BSPP pressure and tank return ports |
| Tare Weight | 18.5 kg dry weight |
| Compatibility | Direct drop-in replacement for 1.0T to 2.5T commercial tail lifts, tippers, and loading ramps |
| Technical Specification | Universal 12V 2.2kW power unit for commercial vehicle tail lifts and tippers with integrated safety relief and manual lowering. |
| Compliance | SAE J200 & ISO 9001 certified |
| Australian Standard | ADR 84/00 & AS/NZS 1418.8 Certified |
| Certification | ADR 84/00 & AS/NZS 1418.8 Certified Commercial Vehicle Tail Lift |
